Product features
Supports Multi-Band and Multi-Operator applications
Converts duplexed RF inputs to simplex outputs to the optical master unit
Supports 5G technology
Principal Parameters
No. | Frequency (MHz) | Coupling (dB) | Ripple (dB max) | Intermodulation (dB max) | Return Loss ( dB min) | Input power range (dBm) | Size (mm) |
L | 617-4200 | 10±3 | 15 | 153,@2×2W | 18 | 24-30 | 483×429×65 |
2 | 617-4200 | 24±3 | 1.5 | 153,@2×20W | 18 | 37-46 | 483×429×65 |
3 | 617-4200 | Port1-4.24±3 Port 5-8:30±3 | 15 | 153,@2×20W | 18 | 37-46 | 483×429×65 |
4 | 617-4200 | 30±3 | 1.5 | 153,@2×20W | 18 | 37-46 | 483×429×65 |
5 | 617-4200 | 37±3 | 1.5 | 153,@2×20W | 18 | 37-46 | 507×440×88 |
